AAW sEMG Flex
Positioning
Section titled “Positioning”AAW sEMG Flex is the most flexible AAW Lab surface EMG front-end board for education, research prototyping, electronics development, and human-computer interaction experiments.
It is designed to help you compare electrode styles and debug the full signal chain before committing to a compact mechanical design.
sEMG Flex product photos: front/back view, optional electrode board, lead wires, and strap-worn setup.
Best For
Section titled “Best For”- Students and developers running a first sEMG or EMG experiment.
- Users comparing dry electrodes, wet electrodes, and onboard dry electrodes.
- Developers using Arduino, ESP32, STM32, oscilloscopes, or external ADCs.
- Small labs building gesture recognition, HCI, robotics, or low-cost biosignal prototypes.
Electrode Options
Section titled “Electrode Options”| Option | Notes |
|---|---|
| Lead-wire wet electrodes | Usually the easiest way to get the first stable waveform. |
| Lead-wire dry electrodes | Useful for repeated experiments without disposable gel electrodes. |
| Onboard dry electrodes | Useful for quick skin-contact tests and mechanical validation. |
What You Still Need
Section titled “What You Still Need”- An ADC, oscilloscope, or MCU acquisition device.
- Battery power or another low-noise isolated supply.
- Software for displaying, recording, or analyzing waveforms.
- Electrode leads and pads if you use external electrodes.
Current Developer-Beta Specs
Section titled “Current Developer-Beta Specs”| Item | Status |
|---|---|
| Supply voltage | 5 V |
| Default gain | About 1000x |
| Recommended sampling rate | >= 1000 Hz recommended, not below 800 Hz |
| Electrode interface | Lead-wire dry, wet, and onboard dry electrodes |
| Module size | 40 mm x 30 mm |
| Includes ADC | No |
| Medical device | No |
More measured values will be added after the first beta hardware is tested.
Next Steps
Section titled “Next Steps”International orders: AAW Lab on Tindie.
China orders: aawlab.taobao.com.
Disclaimer
Section titled “Disclaimer”AAW Lab products are for education, research prototyping, electronics development, and non-diagnostic experiments. They are not medical devices.
